CRANE RAILS SUPPLIER FROM CHINA
15+ YEARS EXPERIENCE OF CRANE RAILS FOR SALE
GloryRail is a leading crane rail supplier in China. We have been engaged in the sales of rail materials for more than 15 years, specializing in providing crane rail system construction services for port warehouse cranes. GloryRail cooperates with seven major steel mills in China to provide high-quality products. Construction of rail track material spot warehouse, storage of various specifications and sizes of crane rail. The ultra-short delivery time meets the customer’s tight construction cycle. At present, it provides long-term crane rails for customers in more than 20 countries and regions in Southeast Asia, North America, South America, Australia, and the Middle East.
In port construction, the quality of the crane rail is very important. GloryRail is currently involved in several large-scale port construction projects in Southeast Asia. It is our aim to ensure the safe and smooth operation of our customers’ rail systems.
TYPES OF CRANE RAILS
Crane rail standards offered by GloryRail include DIN536, JIS E 1103, YB/T5055, and other light and heavy rail types that can be used for Crane rails.
| Type of Rail | Standard | Dimensions mm | Steel Grade | Mass M | |||
| A | F | C | t | kg/m | |||
| A45 | DIN 536 P1:1991 | 55,00 | 125,00 | 45,00 | 24,00 | 50Mn | 22,10 |
| A55 | DIN 536 P1:1991 | 65,00 | 150,00 | 55,00 | 31,00 | 50Mn | 31,80 |
| A65 | DIN 536 P1:1991 | 75,00 | 175,00 | 65,00 | 38,00 | 50Mn | 43,10 |
| A75 | DIN 536 P1:1991 | 85,00 | 200,00 | 75,00 | 45,00 | U71Mn | 56,20 |
| A100 | DIN 536 P1:1991 | 95,00 | 200,00 | 100,00 | 60,00 | U71Mn | 74,30 |
| A120 | DIN 536 P1:1991 | 105,00 | 220,00 | 120,00 | 72,00 | U71Mn | 100,00 |
| A150 | DIN 536 P1:1991 | 150,00 | 220,00 | 150,00 | 80,00 | U71Mn | 150,30 |
| Type of Rail | Standard | Dimensions mm | Steel Grade | Mass M | |||
| A | F | C | t | kg/m | |||
| QU70 | YB/T5055-2014 | 120 | 120 | 70 | 28 | U71Mn | 52.8 |
| QU80 | YB/T5055-2014 | 130 | 130 | 80 | 32 | U71Mn | 63.69 |
| QU100 | YB/T5055-2014 | 150 | 150 | 100 | 38 | U71Mn | 88.96 |
| QU120 | YB/T5055-2014 | 170 | 170 | 120 | 44 | U71Mn | 118.1 |
| Type of Rail | Dimensions mm | Steel Grade | Weight(kg/m) | |||
| A | F | C | t | |||
| CR73 | 135 | 140 | 100 | 32 | U71Mn | 73.3 |
| CR100 | 150 | 155 | 120 | 39 | U71Mn | 100.2 |
At the same time, GloryRail independently produces square steel hoisting rails for overhead cranes.
| Size | Height(mm) A |
Width（mm） B |
Weight(kg/m) |
| 30x30mm | 30 | 30 | 7.065 |
| 40x40mm | 40 | 40 | 12.56 |
| 50x50mm | 50 | 50 | 19.625 |
| 60x60mm | 60 | 60 | 28.26 |
| 70x70mm | 70 | 70 | 38.465 |
| 80x80mm | 80 | 80 | 50.24 |
| 90x90mm | 90 | 90 | 63.585 |
| 100x100mm | 100 | 100 | 78.5 |
| 110x110mm | 110 | 110 | 94.985 |
