DIN536 CRANE RAILS
The German crane rail standard DIN536 is one of the most commonly used rail standards in the crane industry. This standard specifies requirements for hot-rolled crane rails with a flat bottom(type A). The rail models include Rail A45/Rail A55/Rail A65/Rail A75/Rail A100/Rail A120/Rail A150.
The track has a wider track bottom, a stable structure, and better bearing capacity. Mainly used in port cranes. Glorysteelwork provides DIN536 rail material. Various models are always in stock. And can carry out various processing on the track.
For detailed dimensions and weights of all DIN536 rail models, please refer to Table 1. If you need more information about DIN536 or related rail accessories, please contact Glorysteelwork.
Table 1
| Type of Rail | Standard | Dimensions mm | Steel Grade | Mass M | |||
| A | F | C | t | kg/m | |||
| A45 | DIN 536 P1:1991 | 55,00 | 125,00 | 45,00 | 24,00 | 50Mn | 22,10 |
| A55 | DIN 536 P1:1991 | 65,00 | 150,00 | 55,00 | 31,00 | 50Mn | 31,80 |
| A65 | DIN 536 P1:1991 | 75,00 | 175,00 | 65,00 | 38,00 | 50Mn | 43,10 |
| A75 | DIN 536 P1:1991 | 85,00 | 200,00 | 75,00 | 45,00 | U71Mn | 56,20 |
| A100 | DIN 536 P1:1991 | 95,00 | 200,00 | 100,00 | 60,00 | U71Mn | 74,30 |
| A120 | DIN 536 P1:1991 | 105,00 | 220,00 | 120,00 | 72,00 | U71Mn | 100,00 |
| A150 | DIN 536 P1:1991 | 150,00 | 220,00 | 150,00 | 80,00 | U71Mn | 150,30 |
